Catnic Timber Frame Lintel 1200 x 128 x 142mm Black
SKU: LNCND957
The Catnic Cougar Timber Lintel consists of single element lintel with a sloping outer face and duplex corrosion protection, which provides built-in DPC. The product measures 1200 x 128 x 142mm (L x H x W) and is made from galvanised steel which is then powder coated for durability, and adds longevity to the product. All timber frame models must be secured with restraint clips and a batten to prevent lateral deflection (twist) during the building stage to endure the loading weight of 4kN. The timber lintel should be suitably prepped before construction.
Features & benefits
- Duplex Corrosion Protection
- Built-in DPC
- Built-in DPC
- Standard lengths are available in increments of 150mm at lengths up to 3000mm, 300mm at lengths from 3000mm - 4800mm (including 4575 but excluding 4500mm).
IDLNCND957
Building Materials > Lintels > Steel Lintels > Catnic Timber Frame Lintel 1200 x 128 x 142mm Black
https://www.jewson.co.uk/p/catnic-timber-frame-lintel-1200-x-128-x-142mm-black-LNCND957
Get lower prices with a Jewson account
£60.23
inc VAT, Each
50.19
http://schema.org/InStock
£50.19
per metre
Please sign in/register to save items.
The Catnic Cougar Timber Lintel consists of single element lintel with a sloping outer face and duplex corrosion protection, which provides built-in DPC. The product measures 1200 x 128 x 142mm (L x H x W) and is made from galvanised steel which is then powder coated for durability, and adds longevity to the product. All timber frame models must be secured with restraint clips and a batten to prevent lateral deflection (twist) during the building stage to endure the loading weight of 4kN. The timber lintel should be suitably prepped before construction.
Features & benefits
- Duplex Corrosion Protection
- Built-in DPC
- Built-in DPC
- Standard lengths are available in increments of 150mm at lengths up to 3000mm, 300mm at lengths from 3000mm - 4800mm (including 4575 but excluding 4500mm).
Specifications
| Product Name | Catnic Timber Frame Lintel 1200 x 128 x 142mm Black |
| Brand | Catnic |
| Manufacturer Name | Catnic |
| Manufacturer Part Number | CTF51200 |
| EAN | 5017586538853 |
| Compliance Approvals | BBA Certified |
| Warranty Period | 60 years |
| Materials | Galvanised Steel |
| Commercial Or Domestic Use | Both |
| Range | Timber Frame Lintel |
| Colour | Black |
| Application | External |
| Pack Quantity | 1 |
| Country Of Origin | United Kingdom |
| Finish | Galvanised Steel Powder Coated |
| Recyclable | Yes |
| Product Width | 142 mm |
| Product Weight | 3.63 kg |
| Product Length | 1200 mm |
| Moisture Resistant | Yes |
